Aotomatic 6 nozzle filling machine

Product Details:

Place of Origin:	China
Brand Name:	Gracias

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	As discussion
Packaging Details:	fit for shipping
Delivery Time:	20-40work days
Payment Terms:	T/T, L/C
Supply Ability:	30sets per month

Contact Now

All Products

Color Steel Roll Forming Machine (17)

Keel Roll Forming Machine (10)

CZ Purlin Roll Forming Machine (28)

Steel Door Embossing Machine (10)

Door Frame Roll Forming Machine (8)

Shutter Door Roll Forming Machine (14)

Sandwich Panel Roll Forming Machine (5)

Storage Rack Roll Forming Machine (9)

Downspout Pipe Roll Forming Machine (8)

Ridge Cap Roll Forming Machine (9)

Stone Coated Roof Tile Machine (5)

Panel Roll Forming Machine (10)

Highway Guardrail Roll Forming Machine (9)

Cable Tray Roll Forming Machine (7)

Food Processing Machinery (116)

Filling Packing Machine (139)

Wall Panel Extruder (10)

Feed Processing Equipment (27)

Testing instrument (6)

Detailed Product Description

Voltage:	380V	Condition:	New
After-sales Service Provided:	Online Support	Work Pressure:	0.6-0.8 MPA
Warranty:	12 Months	Control System:	PLC(imported Brand)

Rotary lobe pumps designed for handlefrom water-thin to viscid products.

Speciallyfor viscid and foamy liquid products in food.chemical,cosmetic, medical area.

Machine features

Machine construction is made by SUS#304 and aluminum alloy.
Mitsubishi PLC Control system withdigital tounch screen.
volumetric filling system by rotary lobepump driven by AC motors with inverters.Digital LCD touch screen display and setting.

Parameters

Dimension	2500(L)x1700(W)x2300(H)mm
Filling heads	4-6-8-10
Bottle length	160-360mm
Bottle width	140-260mm
Bottle height	250-500mm
Diameter of bottle mouth	≥40mm
Filling capacity	5-50L
Speed	480bottle/hour
Filling error	+-15ml
Voltage	220V/380V,50Hz
Power	3KW
Pneumatic(air-operated)source	0.5-0.65Mpa clean and stably compressed air
