Road Barrier Sheet Metal Roll Forming Machines 12m/min

Road Barrier Sheet Metal Roll Forming Machines 12m/min

  • Road Barrier Sheet Metal Roll Forming Machines 12m/min
  • Road Barrier Sheet Metal Roll Forming Machines 12m/min
  • Road Barrier Sheet Metal Roll Forming Machines 12m/min
Road Barrier Sheet Metal Roll Forming Machines 12m/min
Product Details:
Place of Origin: China
Brand Name: Gracias
Certification: CE
Model Number: Highway guardrail
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: As discussion
Packaging Details: fit for shipping
Delivery Time: 45 work days
Payment Terms: T/T, L/C
Supply Ability: 20sets per month
Contact Now
All Products
Color Steel Roll Forming Machine (17)
Keel Roll Forming Machine (10)
CZ Purlin Roll Forming Machine (28)
Steel Door Embossing Machine (10)
Door Frame Roll Forming Machine (8)
Shutter Door Roll Forming Machine (14)
Sandwich Panel Roll Forming Machine (5)
Storage Rack Roll Forming Machine (9)
Downspout Pipe Roll Forming Machine (8)
Ridge Cap Roll Forming Machine (9)
Stone Coated Roof Tile Machine (5)
Panel Roll Forming Machine (10)
Highway Guardrail Roll Forming Machine (9)
Cable Tray Roll Forming Machine (7)
Food Processing Machinery (116)
Filling Packing Machine (139)
Wall Panel Extruder (10)
Feed Processing Equipment (27)
Testing instrument (6)
Detailed Product Description
Warranty: One Year Voltage: 380V.50HZ.3Phase
Use: Highway Guardrail Steel Sheet Control: PLC
Thickness: 2-3mm Condition: New
After-sales Service Provided: Online Support Color: As Your Request
Highlight:

25T Sheet Metal Roll Forming Machines

,

12m/min Sheet Metal Roll Forming Machines

,

highway guard rail forming machine

Road Barrier Sheet Metal Roll Forming Machines 12m/min



1. Matching material: Feed width: 480mm, forming thickness( 2.0-3.2mm) , Q235 galvanized steel strip
2. Material thickness: 2-3.2mm
3. Main motor power for forming: 22kw
4. Forming speed: 10-12m/ min
5. Hydraulic station power: 11 kw
6. Roll forming stations: About 17
7. Hydraulic pressure: 20 mpa
8. Controlling system: PLC
9. Total weight: About 25 Tons



Machine details

Product name



high way guardrail forming machine


NO. Items Parameters Remark
1

Suitable

Material

 Type GI/PPGI
Width Customized
Thickness 1.5—3.5mm
2

Product

Specifications

 Length Any length Programmed
Length Tolerance ±2mm
3 Working Speed 12m/min Standard machine
4 Control System Mitsubishi/Siemens PLC& transducer Custom
5 Total Power About 30KW Up to final design
6 Total Weight About 15T

Up to final design









































electric decoiler

Road Barrier Sheet Metal Roll Forming Machines 12m/min 0



cutting equipment

Road Barrier Sheet Metal Roll Forming Machines 12m/min 1



gear drive box and transmission equipment

Road Barrier Sheet Metal Roll Forming Machines 12m/min 2

final two and three waves product

Road Barrier Sheet Metal Roll Forming Machines 12m/min 3

two waves sample machine

Road Barrier Sheet Metal Roll Forming Machines 12m/min 4

punch system

Road Barrier Sheet Metal Roll Forming Machines 12m/min 5
