1mm Thickness Steel Tile Shutter Door Making Machine 15m/Min For Garage

Product Details:

Place of Origin:	China
Brand Name:	Gracias
Certification:	CE,ISO
Model Number:	Shutter door

Payment & Shipping Terms:

Minimum Order Quantity:	one set
Price:	As discussion
Packaging Details:	as customer's request
Delivery Time:	20-40work days
Payment Terms:	T/T, L/C
Supply Ability:	50sets per month

Contact Now

Thickness:

0.3-1mm

Voltage:

380v,50hz,3p

Condition:

New

Warranty:

1 Year

Tile Type:

Steel

Use:

Shutter Door

High Light:

Roller station	12 Steps
Shaft Diameter	50mm, -0.01~-0.03(with key-way)
Roller Material	Cr12 with key-way
Heat Treatment	Vacuum quenching upto hardness 58℃
Fine Machining	CNC Lathe after vacuum quenching
Machine Structure	5mm under-frame and 20mm worktable
Motor Power	5.5KW(Lichao,Shanghai)
Hydraulic pressure	25 Mpa
Operation	English Touch Screen
Voltage Standard	380V/3Phases/50Hz
Production Speed	0-30m/min

1	Name of Machine	latest design shutter door forming machine
2	Equipment operation	automatically plc
3	Total power	5.5kw(or as machine'require)
4	Effective Width	312mm
5	Rollers No	124rows
6	OD of Rollers	25-30mm
7	Productivity	15-30m/min
8	Weight	around 3.5T
9	Voltage	380V50Hz 3Phases
10	Machine Dimension (Hightwidthlength)	0.93mX0.67mX6.08m
11	Thickness of sheet	0.4-1.5mm
12	Cutting Device	Cutting by flying saw
13	Range of using	warehouse , supermarket , garage,etc
