Steel Frame CZ Purlin Roll Forming Machine 18m/min 12 Rows

Product Details:

Place of Origin:	China
Brand Name:	Gracias
Certification:	ISO,CE
Model Number:	C/Z

Payment & Shipping Terms:

Minimum Order Quantity:	one set
Price:	Negotiable
Packaging Details:	fit for shipping
Delivery Time:	20-40work days
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	70sets per month

Contact Now

All Products

Color Steel Roll Forming Machine (17)

Keel Roll Forming Machine (10)

CZ Purlin Roll Forming Machine (28)

Steel Door Embossing Machine (10)

Door Frame Roll Forming Machine (8)

Shutter Door Roll Forming Machine (14)

Sandwich Panel Roll Forming Machine (5)

Storage Rack Roll Forming Machine (9)

Downspout Pipe Roll Forming Machine (8)

Ridge Cap Roll Forming Machine (9)

Stone Coated Roof Tile Machine (5)

Panel Roll Forming Machine (10)

Highway Guardrail Roll Forming Machine (9)

Cable Tray Roll Forming Machine (7)

Food Processing Machinery (116)

Filling Packing Machine (139)

Wall Panel Extruder (10)

Feed Processing Equipment (27)

Testing instrument (6)

Detailed Product Description

Voltage:	380V/50HZ 3Phase	Production Capacity:	8-12 Meters Per Minute
Warranty:	1 Year	Control System:	PLC(imported Brand)
Condition:	New	After-sales Service Provided:	Video Technical Support
High Light:	9.8m CZ Purlin Roll Forming Machine , 18m/min CZ Purlin Roll Forming Machine , Hydraulic steel frame roll former

Steel Frame CZ Purlin Roll Forming Machine 18m/min 12 Rows

1. Main features of quickly change CZ purlin machine

The advantages of CZ purlin machine AUTOMATIC size-change type are as follows:

1. Produce different purlin size without changing rollers or spacers.

2. No need changing cutter for different size.

3. Easy operation, low maintenance cost

4. Infinite sizing(any size within machine range),help to save material

5. Optional Punch hole at any position of purlin web side and flange side

1.	Color	Blue	Can paint as your need
2.	Approximate size	9800mm1700mm1400mm	Height without(Cabinet)
3.	Approximate weight	8.5T
4.	Shaft stations	12 rows	With another 7 shafts leveling
5.	Rollers	Cr12 finish machining with heating	One time common lather processing ,two times finish machining
6	Shafts material	45# steel finish machining,diameter 80mm	Tempering treated,can guarantee the hardness
7	Middle panel	20mm
8	Main frame	400H steel
9	Motor	22kw
10	Speed	18-20M/MIN	High speed type
11	Driven	Hydraulic motor
