7.5KW Arch Building Construction PLC For Overlapping Combined Arched Buildings

Product Details:

Place of Origin:	China
Brand Name:	Gracias
Model Number:	ZX-610D

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	As discussion
Packaging Details:	fit for ocean shipping
Delivery Time:	20-60 work days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	45sets per month

Contact Now

All Products

Color Steel Roll Forming Machine (17)

Keel Roll Forming Machine (10)

CZ Purlin Roll Forming Machine (28)

Steel Door Embossing Machine (10)

Door Frame Roll Forming Machine (8)

Shutter Door Roll Forming Machine (14)

Sandwich Panel Roll Forming Machine (5)

Storage Rack Roll Forming Machine (9)

Downspout Pipe Roll Forming Machine (8)

Ridge Cap Roll Forming Machine (9)

Stone Coated Roof Tile Machine (5)

Panel Roll Forming Machine (10)

Highway Guardrail Roll Forming Machine (9)

Cable Tray Roll Forming Machine (7)

Food Processing Machinery (116)

Filling Packing Machine (139)

Wall Panel Extruder (10)

Feed Processing Equipment (27)

Testing instrument (6)

Detailed Product Description

Total Weight:	About 15T	Punching Power:	4.0KW
Straight Part Power:	7.5KW	Max Span:	24M
Control System:	PLC	PLC Type:	Siemens
Material Of Roller Shafts:	45#steel	Roller Rows:	16
High Light:	45#steel CZ Purlin Roll Forming Machine , Siemens CZ Purlin Roll Forming Machine , 7.5KW CZ Purlin Roll Forming Machine

Nut&Bolt Arch Building

Product intruduction:

The machine unit works in the workshop,install and remove easily,

building plank can use over and over again.This technology can

produce and build 9-38 m span, 21 kinds of standard in the shape of a building.

Technical parameters:

Total Weight: About 15T	Punching Part Size:2900mmx1400mmx1300mm
Straight Part Size :10000mmx1400mmx1600mm	Bending Part Size:1600mmx1300mmx2500mm
Oil Pump Part Size: 1200mmx1200mmx1400mm	Punching Power:4.0KW
Straight Part Power:7.5KW	Bending Part Power:7.5KW
Cutting Power :3.0KWoil	Pump Power:7.5KW
Roller Material:45#steel HRC 58-62	Blade Material: Steel # 12
Control System: Electrical Control	PLC: Siemens
Roller Rows:16	Feeding Width:914mm
Effective Width:610mm	Feeding Plate Thickness:0.6-1.5
Groove Depth:203mm	Max Span: 24m
