15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps

15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps

  • 15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps
  • 15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps
  • 15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps
15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps
Product Details:
Place of Origin: China
Brand Name: Gracias
Certification: CE,ISO
Model Number: C/Z
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: As discussion
Packaging Details: fit for ocean shipping
Delivery Time: 30-90 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 20sets per month
Contact Now
All Products
Color Steel Roll Forming Machine (17)
Keel Roll Forming Machine (10)
CZ Purlin Roll Forming Machine (28)
Steel Door Embossing Machine (10)
Door Frame Roll Forming Machine (8)
Shutter Door Roll Forming Machine (14)
Sandwich Panel Roll Forming Machine (5)
Storage Rack Roll Forming Machine (9)
Downspout Pipe Roll Forming Machine (8)
Ridge Cap Roll Forming Machine (9)
Stone Coated Roof Tile Machine (5)
Panel Roll Forming Machine (10)
Highway Guardrail Roll Forming Machine (9)
Cable Tray Roll Forming Machine (7)
Food Processing Machinery (116)
Filling Packing Machine (139)
Wall Panel Extruder (10)
Feed Processing Equipment (27)
Testing instrument (6)
Detailed Product Description
Voltage: 380V/50HZ 3Phase Warranty: 12 Months
Type: C Plus Z Design Cz Purlin Roll Form Machine Production Capacity: 10-20m/min
Condition: New Tile Type: Steel
Control System: PLC Touch/button Screen After-sales Service Provided: Video Technical Support
High Light:

15KW CZ Purlin Roll Forming Machine

,

20m/min CZ Purlin Roll Forming Machine

,

GCr12 steel frame roll forming machine

15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps



CZ purlin machine feeding guide and leveling device
The In-feed Section of the machine allows for variations in sheet width.
Pre-Level Device with 4 over 3 shafts to remove the Coil-set.
Making sure the material is flat enough to be formed (or punched).



CZ purlin machine rollers:One-button control to swap from C to Z, Z to C.

Rollers manufactured from high quality bearing steel GCr15/mold steel Cr12(=D3 steel), CNC lathes, Heat Treatment.
with black treatment or Hard-Chrome Coating for options.
With feeding material guide, body framemade from 450# H type steel by welding
High Precision Servo Motor is adopted to ensure the punching accuracy.


Technical parameters of steel purlins installation making machine :

NO. ITEM PARAMETER
1 Material type GI,PPGI
Width 190-420mm
thickness 0.8-3mm
Yield stress 350-550Mpa
2 Product Cover width 80-300mm
Wave height 80-300mm
Pitch width 40-80mm
3 Decolier Type Automatic with coil car
Suitable coil OD/ID 1200/250-508mm
Max coil width 1000mm
Max capacity 10T
4 Levelling parts roller Diameter:90mm
No.45 steel with quenching
Forming stand 16step
5 Punching parts Type Hydraulic punching
Model material GCr12
6 Main machine Roller 90mm
GCr15 chrome plated
Main machine structure Guide column or wallboard
7 Power requirement Main motor 15kw
Hydraulic pump 7.5kw

15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps 0

15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps 1

PLC:Control system Can setting as request

C /Z Purlin Interchangeable Cold Roll Forming Machine



Oil pump :

C /Z Purlin Interchangeable Cold Roll Forming Machine



Decoiler:

15KW CZ Purlin Roll Forming Machine 20m/min 16 Steps 4



Tag:

Hydraulic CZ Purlin Roll Forming Machine,

5T CZ Purlin Roll Forming Machine,

ISO cold formed steel machine
