3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min

3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min

3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min
video
3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min
Product Details:
Place of Origin: China
Brand Name: Gracias
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: As discussion
Packaging Details: as customer's request
Delivery Time: 20-40work days
Payment Terms: T/T, L/C
Supply Ability: 50sets per month
Contact Now
Detailed Product Description
Voltage: 380V 50Hz 3phases Condition: New
Weight: 3 T Warranty: 12 Months
Control System: PLC After-sales Service Provided: Video Technical Support
High Light:

3T Metal Deck Roll Forming Machine

,

12m/min Metal Deck Roll Forming Machine

,

Cr12 steel sheet roll forming machine

3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min



Product Description



Metal Floor Deck Roll Forming Machine Metal Deck Machine,the finished product are of many features,such as simple shape,large wave height,high intensity and good adhesiveness when pouring the concrete together with the welded steel wire net on-site,in the high story building, it not only can save steel mould board,but also reduce the bearing of the floor: on basis of equal capacity, it reduces the steel amount of engineering useage,so that it saves cost of investment.





Main parameters

Floor Deck PANEL ROLL FORMING MACHINE
1 Suitable to process Color steel
2 Width of the raw material 1000/1200
3 Output width 688/950
4 Rollers 24 rows
5 Power 11kw+7.5kw
6 Thickness of the plate 0.8-1.2mm
7 Productivity 8-12m/min
8 Diameter of the roller 85mm
9 Weight About 10 T
10 Voltage 380V 50Hz 3phase
11 Received table 3
12 Raw material of the cutter Cr12
13 Raw material of the roller Bearing steel



3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min 0

3T Metal Deck Roll Forming Machine For Color Steel Sheet 12m/min 1
