Anode Plate Panel Roll Forming Machine 15m/min 18 Rows

Anode Plate Panel Roll Forming Machine 15m/min 18 Rows

  • Anode Plate Panel Roll Forming Machine 15m/min 18 Rows
  • Anode Plate Panel Roll Forming Machine 15m/min 18 Rows
  • Anode Plate Panel Roll Forming Machine 15m/min 18 Rows
  • Anode Plate Panel Roll Forming Machine 15m/min 18 Rows
Anode Plate Panel Roll Forming Machine 15m/min 18 Rows
Product Details:
Place of Origin: China
Brand Name: Gracias
Certification: CE
Model Number: Anode plate
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: fit for shipping
Delivery Time: 30-50 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 40sets per month
Contact Now
All Products
Color Steel Roll Forming Machine (17)
Keel Roll Forming Machine (10)
CZ Purlin Roll Forming Machine (28)
Steel Door Embossing Machine (10)
Door Frame Roll Forming Machine (8)
Shutter Door Roll Forming Machine (14)
Sandwich Panel Roll Forming Machine (5)
Storage Rack Roll Forming Machine (9)
Downspout Pipe Roll Forming Machine (8)
Ridge Cap Roll Forming Machine (9)
Stone Coated Roof Tile Machine (5)
Panel Roll Forming Machine (10)
Highway Guardrail Roll Forming Machine (9)
Cable Tray Roll Forming Machine (7)
Food Processing Machinery (116)
Filling Packing Machine (139)
Wall Panel Extruder (10)
Feed Processing Equipment (27)
Testing instrument (6)
Detailed Product Description
Voltage: 380V,50Hz/60Hz Condition: New
Weight: 3.8T Tile Type: Steel,Colored Glaze Steel
Warranty: 1 Year Control System: PLC,Automatic Customized( Standard Delta)
Cutting Blade Material: Cr12 Raw Material Thickness: 0.7-1.5mm/0.7-1.0mm/1.2mm
High Light:

Anode Panel Roll Forming Machine

,

15m/min Panel Roll Forming Machine

,

Manual Color Steel Roll Forming Machine

Anode Plate Panel Roll Forming Machine 15m/min 18 Rows

Technical parameters of the anode plate roll forming machine

Equipment components: Man-made uncoiler, Roll forming machine, computer control system, hydraulic control system, cutting Our products are widely used in various industrial factory, civilian building, warehouse and easy steel building manufacturing, and have features such as nice appearance and durable.



Main parameters of roll forming machine

Suitable to process Color steel plate, galvanized sheet,aluminum coils and etc
Width of the feeding material 600mm
Roller station 18 rows or custom
Thickness of feeding material 1.0-1.8mm
Productivity 10-15m/min
Power 11+5.5kw
Rollers' material 45# forging steel
Diameter of shaft 80mm
Weight About 8T
Size 8.5*1.55*1.51mm
Voltage 380V 50Hz 3phases
Roller's material 45# forging steel
Wall thickness of main forming machine 14mm steel plate
Main forming machine body 350 mm H steel

Anode Plate Panel Roll Forming Machine 15m/min 18 Rows 0

Profile drawing

Anode Plate Panel Roll Forming Machine 15m/min 18 Rows 1

Anode Plate Panel Roll Forming Machine 15m/min 18 Rows 2
